12v DC RF Remote Switch 433Mhz
₨ 1500
DC 12V Single Channel Relay Module RF Wireless Switch Receiver + Remote Control Transmitter
Features:
A great replacement for door open button or other switches of devices, widely used in elevating controller, automobile, household appliances, machine tools, alarm system and other automatic control area.
An automatic switch for automatic regulation, with self-lock function, allows safety protection and circuit conversion.
315/ MHz frequency ensure sensitive and strong signal receiving and transmission.
High-quality plastic material and professional PCB circuit board, safe without noise and spark, anti-corrosion, moisture-proof and anti-vibration.
Equipped with a portable remote control for easy and remote operation.
Light and compact size for perfect portability and adaptability, easy to use.
Control Mode:
Self-Lock Mode: Press->On; Press again->Off (Need 1 channel switch and 1 remote control button.) Press one button for working/ ON. Press the same button again for stopping/ OFF.
Inter-Lock Mode: Press->On; Press other button->Off (Need 1 channel switch and 2 remote control buttons.) Press one button for working/ ON, press another button for stopping/ OFF.
Jog Mode: Press and hold->On; Release->Off (Need 1 channel switch and 1 remote control button.) Keep pressing one button for working/ ON. Remove your finger for stopping/ OFF.
Specifications:
1 – Receiver:
Input Voltage: 12VDC
Output Voltage : 220VAC/DC
Loading Current: 10A
Frequency: 315 MHz
Size: Approx. 35 x 32 x 19mm/ 1.4 x 1.3 x 0.7in
2 – Transmitter
Color: White
Frequency: 315/ MHz
Button: 1 Button
Battery: 2016 Button Battery (NOT Included.)
Size: Approx. 35 x 60 x 9mm/ 1.4 x 2.4 x 0.4in
Package Size: Approx. 90 x 80 x 30mm / 3.5 x 3.1 x 1.2in
Package Weight: 42g
